Mimics, Muscles, and Me

01  What is happening here?

One person sat in front of a camera and did two kinds of things, twice each — once with sEMG electrodes on the face, once without. The electrode array measures muscle activity but corrupts the face for any image-based method, so the pipeline does three jobs on top of the raw recording:

With sEMG electrodes — raw frontal video

Electrodes removed — MC-CycleGAN

02  Two modalities, perfectly aligned

There was no hardware trigger LED, so alignment is statistical. After the cut, the sEMG envelope (22 channels, 11 muscles × L/R) shares one time axis with the video — the dashed marker in the heatmap below is the exact frame shown beside it.

video frame 105
99_2S_emotion_12_happy

22-channel sEMG envelope · the marker = that frame

03  Two task paradigms

Two blocks, each recorded once with electrodes (S) and once without (N). The last letter of the session label tells you which.

04  What's in the box

Iterate over MMM.csv — it is the authoritative inventory. The directory tree also holds files no row references.

Seven 3D morphable-model methods

Per-frame parameters for all 46 clean clips; each file has one row per video frame, aligned to video frame i and sEMG row i.

05  Quick start

Download the archive, unzip it, and the dataset lives under MMM/. By downloading you agree to the license terms below (CC BY-NC 4.0).

# unzip if needed
unzip MMM.zip        # -> MMM/

# in Python
# read pid as a string — it is zero-padded and pandas silently converts it
import pandas as pd
df = pd.read_csv("MMM/MMM.csv", dtype={"pid": str})

paired = df[df.emg.notna()]          # 46 clips: EMG + video, frame-aligned
clean  = df[df.type == "normal"]     # 49 electrode-free reference clips
uncut  = df["video_no-cut"]          # untrimmed variants (EMG does not apply)

# load one clip's sEMG — row i == video frame i
emg = pd.read_csv("MMM/" + paired.iloc[0]["emg"])   # 22 columns, 30 Hz

06  Citation & license

Use requires citing the three papers below. The MC-CycleGAN paper covers the electrode-removed videos that every 3DMM parameter set is fitted to.

@inproceedings{buechner2025electromyography,
 doi = {10.1109/CVPR52734.2025.00029},
 year = {2025},
 booktitle = {IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)},
 title = {Electromyography-Informed Facial Expression Reconstruction for Physiological-Based Synthesis and Analysis},
 author = {Tim Büchner and Christoph Anders and Orlando Guntinas-Lichius and Joachim Denzler},
}

@inproceedings{buechner2023improved,
 doi = {10.1007/978-3-031-45382-3_22},
 pages = {262-274},
 year = {2023},
 booktitle = {Advanced Concepts for Intelligent Vision Systems (Acivs)},
 author = {Tim Büchner and Orlando Guntinas-Lichius and Joachim Denzler},
 title = {Improved Obstructed Facial Feature Reconstruction for Emotion Recognition with Minimal Change CycleGANs},
}

@article{guntinas2023high,
  title={High-resolution surface electromyographic activities of facial muscles during the six basic emotional expressions in healthy adults: a prospective observational study},
  author={Guntinas-Lichius, Orlando and Trentzsch, Vanessa and Mueller, Nadiya and Heinrich, Martin and Kuttenreich, Anna-Maria and Dobel, Christian and Volk, Gerd Fabian and Gra{\ss}me, Roland and Anders, Christoph},
  journal={Scientific reports},
  volume={13},
  number={1},
  pages={19214},
  year={2023},
  publisher={Nature Publishing Group UK London}
}
